SAN MV Series

SAN MV Series Vane Air Motor - SAN MV08 AR0009 - AR130

The SAN MV Series Air Motors are compact, reliable, and high-performance pneumatic motors designed for continuous operation in demanding industrial environments.
Specifications :
SKU MV08
max output power 0.79 kW / 1.06 hp - 0.82 kW / 1.10 hp
speed at max output 47 r/min - 6800 r/min
torque at max output 161 Nm / 119 lb-ft - 1.15 Nm / 0.85 lb-ft
min starting torque 207 Nm / 153 lb-ft - 1.4 Nm / 1.03 lb-ft
stall torque 322 Nm / 237 lb-ft - 2.3 Nm / 1.7 lb-ft
free speed 90 r/min - 12000 r/min
air consumption at max output 18.0 l/s / 38.0 cfm
net weight 4.7 kg / 10.3 lb - 2.4 kg / 5.2 lb

₹ XXXX INR + GST

Product Details

The SAN MV Series Air Motors are compact, reliable, and high-performance pneumatic motors designed for continuous operation in demanding industrial environments. Powered by compressed air, they are ideal for applications requiring variable speed, high torque, and safe operation in hazardous or explosive atmospheres.



Product Variation

Image SKU max output power speed at max output torque at max output min starting torque stall torque free speed air consumption at max output net weight Action
0.79 kW / 1.06 hp 47 r/min 161 Nm / 119 lb-ft 207 Nm / 153 lb-ft 322 Nm / 237 lb-ft 90 r/min 18.0 l/s / 38.0 cfm 4.7 kg / 10.3 lb
0.79 kW / 1.06 hp 65 r/min 119 Nm / 88 lb-ft 153 Nm / 113 lb-ft 238 Nm / 176 lb-ft 120 r/min 18.0 l/s / 38.0 cfm 4.7 kg / 10.3 lb
0.79 kW / 1.06 hp 105 r/min 72 Nm / 53 lb-ft 93 Nm / 69 lb-ft 144 Nm / 106 lb-ft 190 r/min 18.0 l/s / 38.0 cfm 4.7 kg / 10.3 lb
0.80 kW / 1.07 hp 190 r/min 40 Nm / 30 lb-ft 51 Nm / 38 lb-ft 80 Nm / 59 lb-ft 370 r/min 18.0 l/s / 38.0 cfm 2.5 kg / 5.5 lb
0.80 kW / 1.07 hp 260 r/min 30 Nm / 22 lb-ft 38 Nm / 28 lb-ft 60 Nm / 44 lb-ft 500 r/min 18.0 l/s / 38.0 cfm 2.5 kg / 5.5 lb
0.80 kW / 1.07 hp 430 r/min 18 Nm / 13.3 lb-ft 23 Nm / 17 lb-ft 36 Nm / 27 lb-ft 800 r/min 18.0 l/s / 38.0 cfm 2.5 kg / 5.5 lb
0.82 kW / 1.10 hp 880 r/min 8.9 Nm / 6.6 lb-ft 11 Nm / 8.1 lb-ft 17.8 Nm / 13.1 lb-ft 1700 r/min 18.0 l/s / 38.0 cfm 2.4 kg / 5.2 lb
0.82 kW / 1.10 hp 1190 r/min 6.6 Nm / 4.9 lb-ft 8.4 Nm / 6.2 lb-ft 13.2 Nm / 9.7 lb-ft 2300 r/min 18.0 l/s / 38.0 cfm 2.4 kg / 5.2 lb
0.82 kW / 1.10 hp 1960 r/min 4.0 Nm / 3.0 lb-ft 5.1 Nm / 3.8 lb-ft 8.0 Nm / 5.9 lb-ft 3700 r/min 18.0 l/s / 38.0 cfm 2.4 kg / 5.2 lb
0.82 kW / 1.10 hp 6800 r/min 1.15 Nm / 0.85 lb-ft 1.4 Nm / 1.03 lb-ft 2.3 Nm / 1.7 lb-ft 12000 r/min 18.0 l/s / 38.0 cfm 2.4 kg / 5.2 lb
