Pneumatic Vibrator
SAN AIR Turbine Vibrator - SANTV
₹ 4000 - 18500 INR + GST
Product Details
SAN AIR / SAN INDUSTRIES PNEUMATIC TURBINE VIBRATOR
Pneumatic vibrator is a type of vibrator that uses compressed air to produce vibratory motion. These vibrators are commonly used in industrial applications for material handling, sifting and screening, and compaction. They are ideal for use in harsh environments, as they are typically durable, low maintenance and able to operate in extreme temperatures.
Pneumatic Turbine vibrators can be powered by compressed air, and they typically use a range of 30 to 100 PSI. They are available in a range of frequencies, which allows for the selection of the appropriate vibrator for a particular application. They have an unbalance Turbine with bearing supports for the turbine. While they are usually maintenance free they have 2 bearings that may need replacement.
Pneumatic vibrator is a type of vibrator that uses compressed air to produce vibratory motion. These vibrators are commonly used in industrial applications for material handling, sifting and screening, and compaction. They are ideal for use in harsh environments, as they are typically durable, low maintenance and able to operate in extreme temperatures.
Pneumatic Turbine vibrators can be powered by compressed air, and they typically use a range of 30 to 100 PSI. They are available in a range of frequencies, which allows for the selection of the appropriate vibrator for a particular application. They have an unbalance Turbine with bearing supports for the turbine. While they are usually maintenance free they have 2 bearings that may need replacement.
Advantages of pneumatic vibrators include:
- Durability: Pneumatic vibrators are designed for use in harsh industrial environments and are able to withstand extreme temperatures, dust and debris.
- Ease of maintenance: With no electrical components, pneumatic vibrators are low maintenance and easy to repair if necessary.
- Energy efficiency: Pneumatic vibrators are powered by compressed air, which is a clean and efficient energy source.
- Noise Level: Turbine Vibrators are silent amongst all other designs of pneumatic Vibrators
Product Variation
| Image | SKU | air pressure | wall thickness of silo hopper | centrifugal force | air consumption | frequency | Action |
|---|---|---|---|---|---|---|---|
| At 6 Bar | 1 mm | 2900 N | 112 LPM | 46000 VPM | |||
| At 6 bar | 2 mm | 3700 N | 300 LPM | 33000 VPM | |||
| At 6 bar | 3,4 mm | 5000 N | 455 LPM | 17000 VPM | |||
| At 6 bar | 5,6 mm | 5900 N | 595 LPM | 14000 VPM | |||
| At 6 bar | 7,8 mm | 7500 N | 750 LPM | 13000 VPM | |||
| At 6 bar | 9,10 mm | 9750 N | 975 LPM | 9500 VPM | |||
| At 6 bar | 11,12 mm | 4800 N | 250 LPM | 5750 VPM | |||
| At 6 bar |
